Petzl S.S.Hanger Plate & Bolt
Petzl
£7.10
High quality stainless steel anchor for typical exterior use
The COEUR BOLT STAINLESS is a high-quality stainless steel anchor made up of a COEUR STAINLESS hanger, a bolt, and a nut.
It is designed for use in typical outdoor environments. It is available in 10 and 12 mm diameters.
Detailed description
- 316L stainless steel assembly that offers excellent resistance to corrosion in typical exterior environments, made up of a COEUR STAINLESS hanger, a bolt, and a nut
- Easy to clip:
- the wide, ergonomic connection point facilitates karabiner clipping
- the width of the attachment point allows installation of two karabiners at the same time
- Reduces wear on connectors: the thickness of the hanger and the rounded edges of the connection point minimize wear on connectors
- Hanger anti-rotation system: textured back keeps the hanger from turning when the anchor is being installed or when it is heavily laterally loaded during use
- Available in two bolt sizes (10 or 12 mm)
- COEUR STAINLESS hangers, available separately:
- for 10 mm diameter bolt (P36AS 10)
- for 12 mm diameter bolt (P36AS 12)
Specifications
- Material: 316L stainless steel
- Certification: EN 959
Ref | P36BS 10 | P36BS 12 |
Dia | 10 mm | 12 mm |
Weight | 110 g | 135 g |
Drill dia | 10 mm | 12 mm |
Total bolt length | 70 mm | 85 mm |
Shear strength in 50 MPa concrete: 25 kN
Pull-out strength in concrete 50 MPa: 10mm - 15 kN, 12 mm - 18 kN
Guarantee: 3 years
