Petzl Steel Hanger Plate & Bolt
Petzl
£3.42
Standard steel anchor for interior use or non-permanent installations
The COEUR BOLT STEEL is a standard steel anchor made up of a COEUR STEEL hanger, a bolt, and a nut.
It is designed for interior use or non-permanent installations. It is available in 10 and 12 mm diameters.
Detailed description
- Economical choice for low-corrosion environments
- Assembly composed of a COEUR STEEL hanger, a bolt, and a nut
- Easy to clip:
- the wide, ergonomic connection point facilitates karabiner clipping
- the width of the attachment point allows installation of two karabiners at the same time
- Reduces wear on connectors: the thickness of the hanger and the rounded edges of the connection point minimize wear on connectors
Hanger anti-rotation system: textured back keeps the hanger from turning when the anchor is being installed or when it is heavily laterally loaded during use
- Available in two bolt sizes (10 or 12 mm)
- COEUR STEEL hangers, available separately:
- for 10 mm diameter bolt (P36AA 10)
- for 12 mm diameter bolt (P36AA 12)
Specifications
Material: Steel
Shear strength in 50 MPa concrete: 10mm - 23 kN,
12mm - 25 kN
Pull-out strength in concrete 50 MPa: 10mm - 15 kN 12mm - 18 kN
Guarantee 3 years
Ref | P36BA 10 | P36BA 12 |
Dia | 10mm | 12mm |
Certification | - | EN 959 |
Weight | 110 g | 135 g |
Drill dia | 10mm | 12mm |
Total bolt length | 85mm | 105mm |
